Olympus OM-D E-M1 Focus Bracketing

Olympus likes to keep on giving to the users who already invested in their systems.  They have recently released version 4 firmware update to their system.  You can find the instructions on how to download this firmware to your Oly here.  Amongst other improvements is the new Focus Bracketing feature.  When Oly is used with one of its PRO series lenses (this is a requirement) like my excellent Zuiko 40-150mm f/2.8 PRO and version 4 installed, Bracketing feature from the Menu now includes Focus stacking.  Focus stacking allows a user to choose to take upward of 99 RAW or JPEG files with a certain amount of "focus shift" from 1-10 steps so that each image captured brings into focus another part of the photograph.  This is very useful in macro or nature photography, where depth of field is often limited.  Once this Focus Bracketing feature is selected, one must also turn on the High Burst mode shooting, and switch it to "silent" - a feature also added with the release of firmware version 4 (funny how that works).  Then, you set your camera up on the tripod (handheld is possible with shorter brackets - like 3 or 4, but more difficult - experiment) - focus on the nearest part of the subject you are interested having in focus, and press the shutter button.  Watch the magic.  When done, download your images into Lightroom CC and process in Photoshop CC (at $10 per month for photogs, Adobe Creative Cloud is a no-brainer for me).  You can also try dedicated focus stacking software that often yields better results.  Photoshop works for me, most of the time.  Here is a super quick tutorial on how to do this in Photoshop CC (Note:  you can use this method for blending manually stacked images too - in case you own another camera that does not have this functionality):

  1. Upload images to Lightroom CC
  2. Select the series of images you are interested in stacking (5 in this example) - click on the first, hold shift, click on the last (range selection)
  3. Right Click and navigate to Edit in => Merge to Panorama in Photoshop
  4. Select "Collage" and uncheck "blend images together"
  5. Wait until Photoshop processes all files (they will be aligned one layer at the time)
  6. Select all of the created layers in Layers pane in Photoshop (there should be 5 in our example) - click on the first, hold shift, click on the last (range selection, just like in Lightroom - hint:  this works just about everywhere for multiple selections)
  7. Got to Photoshop menu, select Edit =>Auto-Blend Layers, select "Stack Images" and "Seamless Tones and Colors - click OK
  8. The 5 layers now have masks where Photoshop has selected only parts in focus to show creating a single image that should be all sharp
  9. If it is not fully sharp, you can mess with individual masks and make minor adjustments
  10. Select all of the layers (like in step 6), click "Flatten Image"
  11. Click to close the file and Photoshop will ask you if you want to save.  Say yes.  Saves file will show up in Lightroom


Here are the "before images" with only portions of each image in focus - CLICK on the image to have them rotate in the order they were taken

Now, after some Photoshop magic, here is one fully in focus:
